ELECTRICAL CHARACTERISTICS
Input Voltage: 230VAC/60 Hz, 0.14A
Transformer Output 16VAC/1.5A, 40VA Max.
Standby Current: Depends on keypad type
OPERATIONAL CHARACTERISTICS
Battery Charger: 12V Sealed Lead Acid
Battery DC Input: 10 to 16 VDC -Current depends on attached devices.
Lock Strike Power: 12VDC constant voltage output / 1.2 A Current Limit
Lock Strike Relay: 5A Form-C, N.O / N.C
Alarm/Auxiliary Relay: 5A Form-C, N.O / N.C
Keypad Power: 12V DC regulated output / 300mA current limit.
Communications: Proprietary Rosslare Secure Format – monitored for wire tamper.
Power LED Red LED indicates connection to input voltage.
Sounder Built-in 8 Ohm, 0.25W Speaker for door-bell, chime and alarm sounds.
ENVIRONMENTAL CHARACTERISTICS
Operating Environment: Indoor Use
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Operating Humidity: 0 to 95% (Non Condensing)
MECHANICAL CHARACTERISTICS
Dimensions: 22.5cm x 22cm x 8.2cm (8.86 x 8.66″ x 3.2″)
Weight: 2.45Kg (5.4 lbs)
SKU:15750012
